Dry Chemiacl Powder Fire Extin
The 12KG Store Pressure Automatic Fire Extinguisher (Model: PD9-AT/PD12-AT) is a professional-grade fire suppression device engineered for large-space fire safety demands. It utilizes High Performance Dry Chemical Powder that meets DIN EN615 standards, enabling rapid extinguishment of early-stage fires without causing secondary damage. Focused on automatic response and large-area coverage, this extinguisher serves as core fire prevention equipment for industrial and commercial settings, effectively handling Class A, B, C Fires (involving solid combustibles, flammable liquids, and gases) to safeguard valuable assets and personnel safety.
Automatic Sprinkler Valve: Equipped with different Temperature Bulbs (customizable for diverse environmental needs), it triggers automatically when the fire temperature reaches the preset threshold, eliminating the need for manual operation and saving critical response time.
Pressure Release Function: Built-in safety valves prevent overpressure risks, ensuring stable operation even in high-temperature environments.
CE Approved Cylinder: The tank undergoes rigorous certification, complying with European safety standards for structural reliability and pressure resistance.
ISO9001 Quality Assurance: All production processes adhere to ISO9001 Quality System requirements, from raw material selection to final assembly, guaranteeing consistent product quality.
100% Helium Leak Detected: Each unit passes strict helium leak testing to avoid gas leakage, ensuring long-term storage stability and immediate activation when required.
Phosphated Treated Cylinder: The tank surface is first subjected to phosphating treatment to enhance corrosion resistance, then covered with a Powder Coated Layer—effectively withstanding harsh industrial conditions (such as humidity and chemical fumes) and extending service life.
High-Density Powder Storage: The internal cavity is optimized for 12KG Dry Chemical Powder storage. Ensuring uniform powder distribution and smooth spraying without blockages.
Precision Pressure Gauge: A built-in Pressure Monitoring Gauge allows real-time monitoring of internal pressure. Helping users identify potential faults (e.g., insufficient pressure) in advance.
Chemical Workshops: Addressing fires caused by flammable liquid (e.g., oil, solvents) and gas leaks.
Industrial Plants: Safeguarding production lines and machinery against multi-type fires.
Large Warehouses: Protecting stored solid goods (e.g., wood, paper) from Class A fires.
Shopping Mall Backends: Covering storage areas and equipment rooms prone to electrical or liquid fires.
Installation: Mount the extinguisher on a stable wall (1.5m above the ground) in a well-ventilated area, avoiding direct sunlight or proximity to heat sources. Ensure the Temperature Bulb is not obstructed by obstacles.
Daily Check: Conduct monthly inspections of the pressure gauge (normal range: 1.2-2.5MPa) and check for cylinder corrosion or powder leakage.
Usage Steps: 1) If automatic activation fails, manually Pull the Safety Pin; 2) Hold the extinguisher in an upright position; 3) Aim at the Base of the Fire (not the flames); 4) Press the nozzle to spray powder evenly.
Caution: Maintain a minimum 3-meter distance from electrical equipment to avoid electric shock; clean residual powder after use to prevent equipment damage.
