PD10LB-AL
VICTORY
2L
0.2kg
Dry Chemiacl Powder Fire Extin
| Model Number | PD10LB-AL |
| Capacity(lb/kg) | 10.5(4.76) |
| Cylinder Diameter(in/mm) | 5.51(140) |
| Height(in/mm) | 20.16(512) |
| Width(in/mm) | 9.21(234) |
| Discharge Time(s) | 22 |
| Fire Rating | 4-A:60-B:C |
| Extinguisher Weight(lb/kg) | 17.97(8.15) |
| Packing Size(L×W×H)(in/mm) | 7.09×5.91×20.87(180×150×530) |
| Working Pressure psi/bar) | 195(13.44) |
| Operation Temperature(F/C) | -40~120(-40~49) |
| UL list File Number | EX 26837 |
| USCG Approval Number | 162.028 EX 26837 |
* Transport Classification:Non-Flammable,Non-Toxic Gas. UN No.1044 Class 2.2
