PD20LB-S
VICTORY
2L
0.2kg
Dry Chemiacl Powder Fire Extin
Model Number | PD20LB-S |
Capacity(lb/kg) | 20(9.07) |
Cylinder Diameter(in/mm) | 7.16(182) |
Height(in/mm) | 23.22(590) |
Width(in/mm) | 10.63(270) |
Discharge Time(s) | 23 |
Fire Rating | 6-A:80-B:C |
Extinguisher Weight(lb/kg) | 32.83(14.89) |
Packing Size(L×W×H)(in/mm) | 8.27×7.48×24.01(210×190×610) |
Working Pressure psi/bar) | 195(13.44) |
Operation Temperature ( F/C) | -40 ~ 120 (-40~49) |
UL list File Number | EX 26837 |
USCG Approval Number | / |
* Transport Classification:Non-Flammable,Non-Toxic Gas. UN No.1044 Class 2.2
